Geisler Frame Safety Tests and Function Tests: Without Mods
In my previous Geisler frame videos I made modifications to the frame to improve it in my opinion. But since I got a second frame for another experiment (I'll release a video on that soon too) I wanted to see if the Geisler passes safety and function checks without these mods. TL;DR it does.
Here are my tips and tricks to getting a clean result when routing an 80% AR lower using the 5D tactical jig.
Timeline:
0:15 General Tips & Tricks
5:47 Pilot Hole Drilling
7:15 Milling the Fire Control Group Cavity
21:35 Drilling the Fire Control Group Holes
This is a Geisler model 1917 80% frame overview. One of the things I focus on is the content from SwissBianco's review and where I agree/disagree with it after building one.
It's well known that Rit Dye on polymer frames doesn't go very deep. In this video we experiment with a grey Geisler frame to figure out just hot deep that is and also what the dye looks like if we stipple the frame after dying it.
The rest of this 5-part series is available on my YouTube channel of the same name. This first video is posted here because for some reason YouTube removed it and rejected my appeal despite it not breaking a single one of their policies.
I loved the look of lightening cuts on AR lowers, but many of the coolest designs weren't available on 80%s. I also thought it would be cool to be able to tweak lightening cut designs to fit my desires.
This is the first installment of exploring whether it is possible to do lightening cuts on a hobby CNC geared mostly towards wood cutting.
I'm also curious whether lightening cuts will even look good on a forged lower in the end or if you need the freedom of billet to really tie together an aesthetic theme.
If you've got detailed questions, happy to take them. My email is my channel name at Protonmail dot Com
This is my overview of the Geisler Model 1917 80% pistol frame. It’s not a review, as I try my best (although I know I failed in some spots) to keep my opinion out of it and focus only on the functionality, the methods of building, etc. There were already a few reviews, so I wanted to focus more on a holistic view of building one and whether it results in a safe product, as there wasn’t a lot of that type of information online.
But! As I explain at several points, much of this content is an examination of concerns voiced in a review by SwissBianco, how I addressed them, and whether or not they impact final functionality and safety of the firearm.
Spoiler alert: if you put the skills, time, and effort into the build you will end up with a perfectly functioning and objectively safe weapon.
If you want to watch a multi-hour video of exactly how I built it, you can do that here: https://odysee.com/@NotaGunTuber:a/Geisler-80-Percent-Build-Follow-Along:2
Timeline of sections of this video:
Introduction, Why I Built, Why I Filmed- 0:00
Rail height or frame/slide gap- 3:00
Trigger housing fit- 4:48
Width of takedown lever slot- 8:40
Perfecting bend in rear rails- 9:42
Magazine fit- 12:10
Aggressiveness of stippling texture- 13:22
Safety testing and results- 15:53
Cons, Neutrals, Pros- 21:11
Conclusions- 25:00
This video will dive into (probably too much) detail on building out a Geisler 80% frame from scratch. Although it tackles the whole build, which has a lot of similarities to P80s, the main goal here was to illustrate steps unique to this frame and how you can get a fantastic result. In the timeline of sections below I have put a ^ at the beginning of any section that is Geisler specific.
If you are looking for a shorter, post build overview of the frame, you can find that here: https://ody.sh/4Cg2h8etgC
^Intro and Overview- 0:00
Bulk removal of rail blockers and channel blocker- 16:12
Dremeling, sanding, and polishing the channel- 20:05
Sanding and polishing of frame top- 41:09
Drilling holes- 42:31
^Figuring out takedown lever slot approach- 44:23
^Shimming trigger housing- 48:32
^Perfecting bend in rails- 56:42
Making rails coplanar- 1:00:54
^Executing takedown lever slot shim- 1:08:08
^Bonus fun: Stippling test, one section- 1:16:18
^Cleanup of takedown lever slot shim- 1:21:47
^Bonus fun: Stippling, full results and discussion- 1:26:36
Optimization and safety- 1:28:49
*Includes content on ensuring smooth function, breakin, as well as function and safety tests
